 AC-800C |
|---|
 AC-800C |
Air Cleaner
C type-Odor Application
PATENT PENDING
-
Improve Productivity
-
OSHA&EU-OSHA Compliance
-
Adjustable Inlet
-
Filter Area 1,200 s.f./111m²
(The air of space circulate six times per hour.)
FEATURES
Aluminum Mesh
85% stainless net
35% Pre-pleated Filter
Activated Carbon filter(30kg)
4-Stage Filtration
Stage 1. ＞
Aluminum Mesh
Capturing larger particles
Stage 2. ＞
85% stainless net
Capturing larger particles
Stage 3. ＞
35% Pre-pleated Filter
Capturing 35% of the 2-10 micron smail particales and absorbing oil for life extension of pleated filter
Stage 4. ＞
Activated Carbon Filters (30kg)-Fill-up type
Filter out noxious odor caused by formaldehyde, ammonia or glue.
SPECIFICATIONS
We reserve the right to make changes in SmartVent products in order to improve design or performance characteristics without further notice.
HOW IT WORKS
AC-800C Airflow Directions
STEP 1.
Air extracted via inlet 1 or 6 ,inlet 1 could attaced with hose or fume arm.
STEP 2.
The air pass through the Aluminum Mesh 2 and steel net 3 ,for seizing larger particles.
STEP 4.
Before exhusted out to the workplace, noxious odor caused by formaldehyde, ammonia or glue will been filtered by Activated Carbon Filters (30kg) 5
STEP 3.
Conducted through 35% pre-filter 4 for small particales capturing and oil absorption.
STEP 5.
Clean air is returned back to the workplace.
APPLICATIONS
Remove Odor
Welding Fumes
Dust Collection
Remove Odor
