AC-2000C

Air Cleaner

Air Cleaner C type-Odor Application

Air Cleaner
C type-Odor Application

PATENT PENDING

  • Improve Productivity

  • OSHA&EU-OSHA Compliance

  • Adjustable Inlet

  • Filter Area 2,000 s.f./185m²
    (The air of space circulate six times per hour.)



FEATURES

Revolutionary Characteristics

Stage 1. >

Easy-access door for mainte nance.

Stage 2. >

Filter out noxious odor caused by formaldehyde, ammonia or glue.

Stage 3. >

Heavy gauge power coated steel.

Stage 4. >

Adjustable inlet 1x 27 inch (26 x 686mm)

Stage 5. >

Unit could install Ø 6”x2 or Ø 8”x1 fume arm or tube with fume hood.

3-Stage Filtrations

Stage 1. >

Aluminum Mesh

Capturing larger particles

Stage 2. >

Activated Filled Carbon Filter(50kg)

Removing noxious odor caused by formaldehyde, ammonia or glue

Stage 3. >

Carbon filter

Removing peculiar smell and smaller particle

Optional Accessories

 > HEPA Module

 > Efficiency 99.995%

 >

Spec.: 24 x 30 x 8 inch (610 x 762 x 205 mm)

SPECIFICATIONS

Air Cleaner C type-Odor Application

 We reserve the right to make changes in SmartVent products in order to improve design or performance characteristics without further notice.



HOW IT WORKS

Air Cleaner C type-Odor Application

AC-2000C Airflow Directions



STEP 1.

Air extracted via inlet 1 or 2 , and passing through the Aluminum Mesh 3 , for seizing larger particles.

STEP 2.

The air is being conducted to Carbon Filter 4 .

STEP 3.

As air slowing down inside the Activated Carbon filter chamber, partical will fall down onto the drawer of dust collector, meanwhile, noxious odor caused by formaldehyde, ammonia or glue will been filtered.

STEP 4.

The remaining dust could filtered by optional accessories HEPA as 99.99% of 1 micron partical filtration.

STEP 5.

Clean air is returned back to the workplace 5 .

APPLICATIONS

APPLICATIONS
Remove Odor
Remove Odor

press to zoom
Welding Fumes
Welding Fumes

press to zoom
Dust Collection
Dust Collection

press to zoom
Remove Odor
Remove Odor

press to zoom
